IN-B3000 Medical Urinalysis Test Full Automatic Micro Albumin Urine Sediment Analyzer
Work Principle Use flow counting cell technology, medical image scanning technology and artificial intelligence identification technique to capture real images of urine formed elements, and then locate, track, recognize, classify and count them.
The most advanced Four channels design Single sample sucking needle with four-channels counting cell technology, one channel detecting and others subsiding or cleaning, fully guarantee the test speed is 120 samples/hour.
Sample loading system Fully automatic track type walk away mode: after placing the samples, the instrument automatically keeps conducting samples scanning, locating, mixing, aspiration and detection without centrifugation. The Max. sample loading capacity is 6 racks of 10 tubes.
Auto focusing technology Automatic focusing technology for microscope without focusing liquid, fully guarantee clarity of the images and reduce maintenance costs.
Washing system Use high precision PTFE coating sample sucking needle to clean the pipeline more thoroughly, to prevent cross contamination as much as possible.
Main Technical Specifications:
Test items: RBC, WBC, Epithelial, Casts, Crystals, Bacteria, Yeast, Sperm, Mucus,WBCC and other components in urine; RBC morphology analysis (Erythrocyte phase) Detection principle:Flow cell digital imaging technology, medical image fusion technology, artificial intelligence identification technique. Channel: Four channels fixed flow counting cell Detection speed: 120~160 samples/h Sample volume: Minimum volume: 3 ml Aspirating volume: l ml Test sensitivity: 5 objectives/ul Accuracy:>95% Repeatability: CV <10% Cross contamination rate: <0.05% Data storage: 200000 Report model: International general quantitative unit: unit /ul & HPF, complete and illustrated report, with urine chemistry test results and urine formed elements test results Environment: Temperature 15°C~35°C, Optimum temperature 20°C~25°C, Relative humidity≤75% Power supply: AC 100-240V 50/60HZ Dimensions(main unit): 660mm*440mm*570mm(L*W*H) Weight: 33kg
Our company is a leading exporter and supply chain service provider of medical machine with more than 8 years' experience. Our main products include X-ray machine, B ultrasound scanners, ECG, patient monitor, ICU equipment, Lab equipment, and other related medical disposables. We have exported products to more than 50 countries and built long term partnerships with clients. Your satisfaction is our duty! It will be our great honor to serve you. We do hope we can offer you more help in medical field and build the long term business relationship with you.
Top Quality: We have strict quality control system and enjoy good reputation in the market.
Excellent Service: We treat clients as friend and aim at building long term business relatiionship.
OEM Accepted :We Can print your own logo on the products.
Unbeatable Price: We always ensure high price performance to benefit our customers.
Timely Delivery:Your order shall be shipped once finished .
After-Sale Service:All Products Have One Year Warranty.
Packaging & Shipping
1. We ship the Urine Sediment Analyzerby air or sea for you.
2. Our Urine Sediment Analyzerwith standard export packing.
3. No matter what delivery way , all depending on your actual requirements.
How to buy your products ?Do you have distributor in our country?
You can buy the products from our company directly.Normally the procedure is:Sign the contact ,payment byT/T, contact the shipping company to delivery the goods to your country.
What is the warranty?
The free warranty is one year from the day of Commissioning qualified.
Can we visit your country ?
Of course,we willprepare for everything in advance if it is necessary .Generally,it is require that customers must have build agency relationship or business relationship with our company.
How long is the validity of quotation?
Generally,our price is valid within one month from the date of quotation .The price will be adjusted appropriately according to the price fluctuation of raw material and changes in market .
Do you have the CE certificate ?
Yes, most of our products have the CE certificate.
